2, 2′-Bis(ethylferrocenyl)propane, Catocene, Tanyun chem

详情页(上).jpg Product parameters

Executive standard: Q/YTY001-2014

Chines alias: 卡托辛

English alias: Catocene

CAS RN: 69279-97-6; 37206-42-1

1. Physical and chemical properties:

1.1 Molecular formula: C27H32Fe2

1.2 Molecular weight: 468.25

1.3 Structure formula:

Structure formula

1.4 Stability and reactivity: Stable at room temperature and in sealed container.

2. Technical indexes:

Item	Index
Purity(titration),% (m/m)	≥97.5
Fe content,%(m/m)	23.3-24.3
Viscosity,(25℃) Pa·s	< 2.8
Density,(20℃) g/cm3	1.2910-1.2960
Moisture content,%(m/m)	< 0.08
Volatilization loss,(80±1)℃,%(20±1)*102Pa,12h	< 2.0
Insoluble,%(m/m)	< 0.10
Acidity,mmol/100g	< 0.30
Appearance	Brown red viscous liquid

3. Application: 2,2′-Bis(ethylferrocenyl)propane has been used as an efficient burning rate catalyst in composite solid propellants, which is possessed of the features of excellent overall and small removing properties. As a kind of bisferrocene derivative, 2,2′-bis(ethylferrocecnyl)propane can improve the combustion rate and reduce the pressure exponent with the application of AP-based oxidizer in composite solid propellants.

4. Safety instructions: Low toxic. LD50(Rat): > 20,000 mg/kg; Mouse, oral: LD50> 500mg/kg.

5. Packing: Two plastic casks in a wooden case. Net Weight: 10 kg/cask; 20 kg/case.

6. Storage: Stored in a cool, ventilated place. Casks should be sealed with nitrogen. Avoid heat and exposure. The shelf life is 12 months after manufacturer date. It is still available if retest result is qualified after expire date.

7. Transportation: Keep upright when transported. Avoid violent collision and exposure. Do not mixed with strong oxidizer.

详情页(下)1.jpg 详情页(下)4.jpg 详情页(下)2.jpg 详情页(下)3.jpg

Customization

We are able to develop custom-made products according to the clients'requests

● We have 4 R&D bases (Shanghai, Hangzhou, Suzhou, Yingkou), hundreds of synthesis leading experts and PhDs in chemistry.

● We own experienced R&D capability and rich experience in production, and provides you with a variety of organic chemicals, medical intermediates research, development, production, etc. on behalf of a range of high quality customized service.

● We have developed over 20 kinds of custom chemicals for the customers, and 3 kind products, such as copper chromite dehydrogenation catalyst, have already consigned a usage in batch with customer sign-off. 2 invention patents have been applied. 6 kinds of customized products, such as efficient curing agent, have been applied in pilot trials and pilot production by customers.

● More than 10 kinds of chemicals have been in R&D, such as nano-waterproof materials, oil additives and fine chemical intermediates.
